Peppers Cable Gland Type A  - (Single Compression Gland for Unarmoured Cable)

“A” type glands are certified Flameproof Ex d, Increased Safety Ex e, Restricted Breathing Ex nR and Dust Protected Ex ta. They are suitable for use in Zone 1
and 2 for Gas Groups IIA, IIB and IIC and additionally for use in Zones 20, 21 and 22 for Dust Groups IIIA, IIIB and IIIC. Commonly referred to as “stuffing
glands” they provide a controlled pull resistant environmental displacement seal on the cable outer sheath, minimising damage to cables that exhibit “cold
flow” characteristics. The gland maintains IP66 & IP68 to 50 metres. It is supplied with an IP O-ring seal as standard on metric entry threads. Options are
available for use with LSOH cables and extreme temperature applications.

Example Part Numbering(See below for details)
A2LBF/NP/20/M20
A Type of gland featuring controlled displacement sealing
2 Neoprene Seals (2) - Silicone (3) - Neoprene/Lead (1) - Silicone/Lead (4)
L Peppers Standard Designation
B Aluminium (A) / Brass (B) / Stainless Steel (S)
F Multiple Certification
Options
C PVC Shroud (C) - PCP Shroud (P) - Silicone LSOH Shroud (3)
K-V-H Locknut & Nylon (K), Fibre (V) or PTFE (H) IP Washer
T Including Earth Tag
S Including Serrated Washer
1 Quantity per kit
NP Nickel Plated
20 Gland shell size
M20 M20 x 1.5mm Male Entry Thread
Optional，Accessories
Locknut Brass (ACBLN) / St Steel (ACSLN) / Aluminium (ACALN)
Earth tag Brass (ACBET) / St Steel (ACSET) / Aluminium (ACAET)
IP Washers Nylon (ADXB2B.COM，高温线SW) / Fibre (ACFSW) / PTFE (ACPSW)
Serrated Washers Stainless Steel (ACSSW)
Shrouds  PVC (ACSPVC) / PCP (ACSPCP) / Silicone LSOH (ACSSIO)
